Packless Diaphragm Valve - Straight Flare To Flare ( Tuffy 215-8 )
A14836
Packless Diaphragm Valve - Straight Flare To Flare ( Tuffy 215-8 ) Compatible with all CFC, HCFC, and HFC Refrigerants and oils UL/cUL Listed - Conforms to Pressure Equipment Directive 97/23/EC Forged Brass Body with full size openings for maximum flow and minimum pressure drop Thermally stable hand wheel for operation in wide temperature ranges
Connections: 1/4''
Flare ends
Weight: .27kg / .59lb
-40 to 149 Celsius, -40 to 300 Farenheit
A Open, 2.7'' (69 mm)
B 1.32'' (34 mm)
C 1.38'' (35 mm)
D .62'' (16 mm)
